Cessna
340
|
|
SPECIFICATIONS
|
| Price:
|
$290,000 |
| Engine
make/model: |
Cont.
TSIO-520-NB |
|
Horsepower@altitude: |
310 to
20,000 ft. |
| Horsepower
for takeoff: |
310 |
| TBO hours: |
1400 |
| Fuel type: |
100/100LL |
| Propeller
make/type: |
McCauley
CS/76 in. |
| Landing
gear type: |
Tri/Retr. |
| Max ramp
weight (lbs): |
6025 |
| Gross
weight (lbs): |
5990 |
| Max landing
weight (lbs): |
5990 |
| Zero fuel
weight (lbs.): |
5630 |
| Empty
weight (lbs): |
4142 |
| Useful Load
(lbs): |
1848 |
| Payload
(full fuel) (lbs): |
630 |
| Usable fuel
(gals): |
203 |
| Oil
capacity (quarts): |
12 |
| Wingspan:
|
38 ft. 1
in. |
| Overall
length: |
34 ft. 4
in. |
| Height: |
12 ft. 7
in. |
| Wing area
(sq. ft.): |
184 |
|
Wing loading (lbs/sq. ft.): |
32.6 |
| Power
loading (lbs/hp): |
9.7 |
| Wheel
track: |
12 ft. 11
in. |
| Wheel base: |
10 ft. 3
in. |
| Seating
capacity: |
6 |
| Cabin
doors: |
1 |
| Cabin
width: |
46.5 |
| Cabin
height: |
49 in. |
| Baggage
capacity (lbs): |
930/53 |
|
PERFORMANCE
|
Cruise speed (knots):
| |
Altitude |
Economy |
| 75% power: |
25,000 |
229 |
| 65% power: |
25,000 |
219 |
| 55% power: |
25,000 |
202 |
| Max
range (with reserve) (nm): |
| 75% power: |
25,000 |
1106 |
| 65% power: |
25,000 |
1248 |
| 55% power: |
25,000 |
1377 |
| Fuel
consumption (gph - est.): |
| 75% power: |
34 |
|
| 65% power: |
30 |
|
| 55% power: |
26 |
|
|
Estimated
endurance
(65% power w/1 hr reserve) (hrs) |
5.5 |
| Stall speed
(flaps up) (knots): |
79 |
| Stall speed
(flaps down) (knots): |
71 |
| Best rate
of climb (fpm): |
1650 |
|
Single-engine rate of climb (S/L - fpm): |
315 |
| Service
ceiling (ft.) |
29,800 |
|
Single-engine service ceiling (ft.): |
15,800 |
| Takeoff
ground roll (ft.): |
1615 |
| Takeoff
over 50-ft. obstacle (ft.): |
2175 |
| Landing
ground roll (ft.): |
770 |
| Landing
over 50-ft. obstacle (ft.): |
1850 |
|
All specifications are for
a 1980 Cessna 340A. |
